Emerson Vertiv Online UPS
Reliable Power, Uninterrupted Performance!
True Online Double Conversion UPS with optional built - in galvonic isolation & with extended runtime capabilities
Liebert GXT MT+ Series systems is true double conversion online UPS systems designed to provide with a capacity of 6/10/20 kVA. Liebert GXT MT+ units feature total isolation of the load from the mains – isolating input and output sections, and
making the systems ideal for Data Networks / Small Data Centers/VOIP Applications application. The units support hot standby configuration, making them suited
for critical applications like banks.
FEATURES
- IGBT Based Rectifier
- True Online Double Conversion with DSP Control Technology for High Performance and Reliability.
- New Graphical LCD Display Provides UPS Data, Alarms and Helps in faults diagnostics and trouble shooting.
- Double Conversion Efficiency upto 90%.
- Active Input Power Factor Correction 0.99.
- 0.8 Output Power Factor.
- Wide Input Voltage window (110 - 280 Vac) for Indian Environmental Condition and for Optimized Battery Performance.
- Configurable Output Voltage (200/208/220/230/240 Vac.)
- Generator Compatible with Wide Input Frequency Range (40 Hz-70 Hz).
- 4 Stage Extendable Charging Design for optimized Battery Performance.
- Adjustable Battery Charging Current 1/2/4/6 Amps according to Battery Capacity and Rating
- 50/60 Hz Automatic Frequency Converter Mode.
- Intelligent Monitoring with Standard RS232/USB Port Plus Slot Available for RS485/Dry Contact/SNMP Card.
- Inbuilt OVCD.
Technical Specification
| MODEL | GXT MTX+ 06 kVA | GXT MT+ 06 kVA | GXT MT+ 10 kVA | GMT MT+ 10 kVA | GMT MT+ 20 kVA |
|---|---|---|---|---|---|
| PHASE | 1 phase in / 1 phase out | 3 phase in / 1 phase out | |||
| CAPACITY | 6000 VA / 4800 W | 6000 VA / 4800 W | 10000 VA / 8000 W | 10000 VA / 9000 W | 20000 VA / 18000 W |
| INPUT CHARACTERISTICS | |||||
| Nominal Voltage | 230 VAC (1Ph + N) | 3 × 400 VAC (3Ph + N) | |||
| Voltage Range | 160–300 VAC (1-phase) @ 100% load | 305–478 VAC (3-phase) @ 100% load | |||
| Frequency Range | 46–54 Hz or 56–64 Hz | ||||
| Power Factor | ≥ 0.99 @ 100% load | ||||
| THDi | < 6% @ 100% load | ||||
| OUTPUT CHARACTERISTICS | |||||
| Output Voltage | 208 / 220 / 230 / 240 VAC | ||||
| AC Voltage Regulation (Batt. Mode) | ± 1% | ||||
| Frequency (Synchronized) | 46–54 Hz or 56–64 Hz | ||||
| Frequency (Batt. Mode) | 50 Hz ±0.1 Hz or 60 Hz ±0.1 Hz | ||||
| Current Crest Ratio | 3:1 (max) | ||||
| Harmonic Distortion | <3% THD (Linear) <7% THD (Non-Linear) |
≤2% THD (Linear), ≤5% THD (Non-Linear) | |||
| Transfer Time (AC → Batt.) | Zero | ||||
| Inverter → Bypass | Zero | ||||
| Waveform (Batt. Mode) | Pure Sinewave | ||||
| AC Mode Efficiency | >84% | 91% | >92% | >92% | >92% |
| ECO Mode Efficiency | 97% | ||||
| BATTERY CHARACTERISTICS | |||||
| Battery Type | SMF | SMF or Tubular | |||
| Numbers | 16–20 (adjustable) | 18–20 (adjustable) | |||
| Charging Current (Max) | 6A (1–6 selectable) | 12A (2–12 selectable) | |||
| Charging Voltage | 273 VDC ±1% (Based on 20 batteries) | ||||
| INDICATORS | |||||
| LCD Panel | UPS status, Load level, Battery level, Input/Output voltage, Discharge timer & Fault conditions | ||||
| ALARM | |||||
| Battery Mode | Sounding every 4 seconds | ||||
| Low Battery | Sounding every second | ||||
| Overload | Sounding twice every second | ||||
| Fault | Continuously sounding | ||||
| PHYSICAL | |||||
| Dimensions (D×W×H mm) | 369×190×630 | 369×190×318 | 442×190×318 | 592×250×576 | 592×250×826 |
| Net Weight (kg) | 72 | 21 | 23 | 28 | 45 |
| ENVIRONMENT | |||||
| Operating Humidity | 0–95% RH @ 0–40°C (non-condensing) | ||||
| Noise Level | <65 dB | <55 dB | <58 dB | <60 dB | <60 dB |
| MANAGEMENT | |||||
| Smart RS-232 / USB | Windows® 2000/XP/Vista/7/8, Linux, Unix & macOS | ||||
| Optional SNMP | Power management via SNMP manager & web browser | ||||
